特点

输入测量

  • 电能质量：实际功率、视在功率、无功功率、功率因数、峰值因数（V和I）、相角
  • 电流谐波（基于IEC 61000-3-2至第40次谐波）
  • 侵入电流

开关测量

  • Rds-on和Vce-sat
  • 开关损耗（功率和能量）
  • 压摆率（dv/dt和di/dt）
  • 调制（占空比、脉冲宽度、周期、频率等，随时间变化图）

输出测量

  • 输出波纹
  • 接通和断开时间
  • 瞬态响应时间
  • 效能

频率响应测量

  • 电源抑制比 (PSRR) – Bode
  • 控制回路响应 – Bode（自动测量相位裕量和增益裕量）

Keysight 的InfiniiVision 4000 X-系列示波器的强大软件包可实现多种自动化电源特性测量，包括临界频率响应测量（仅限 3000T X- 系列），如电源抑制比 (PSRR) 和控制回路响应。 该软件包还支持基于件硬的通过/失败掩码测试，以及USB PD触发和解码。

免费试用

获取 D4000PWRB 的 30 天试用许可证。

D4000PWRB 功率测量选件可通过 Keysight InfiniiVision 4000 X 系列示波器上的许可证文件启用。

Power Measurements software for oscilloscopes

想要深入了解 D4000PWRB？

拓展 4000 X 系列示波器的功率测量功能
